EVH - Wolfgang Special QM, Baked Maple Fingerboard, Tiger Eye Glow

Road-tested in arenas around the world, the Wolfgang® Special is a purebred music-making machine, designed with stunning style, giant sound and high-speed playability.

The Wolfgang Special QM features a basswood body with an arched quilt maple top and a robust graphite-reinforced bolt-on quartersawn baked maple neck. The neck is carved and rolled to Eddie Van Halen's exacting specifications and features a hand-rubbed satin urethane finish on the back. Primed for high performance, energetic riffing and blazing leads, the 12"-16" compound radius baked maple fingerboard has 22 jumbo frets and black dot inlays. Truss rod adjustments have also never been easier thanks to a spoke wheel conveniently located at the base of the neck.

A pair of flagship custom-designed EVH® Wolfgang Alnico 2 humbucking pickups are mounted directly to the body, providing dynamic yet articulate voicing, as well as endless sustain for powerful chords and melody lines. A sturdy and dependable EVH-branded Floyd Rose® locking trem and Floyd Rose locking nut work in tandem for precise tuning even with extreme changes in pitch, while the EVH D-Tuna® retunes to drop-D and back with strict accuracy at the flick of a finger. The volume knob with treble bleed circuit has a 500K EVH Bourns® low friction pot for smooth swells and a tone control knob with a 250K Bourns high friction tone pot that prevents accidental tone shifting.

SPECIFICATIONS

General

• Model Number: 5107701580

• Series: Wolfgang® Special

• Color: Tiger Eye Glow

• Number of Strings: 6

• Orientation: Right-Hand

Body

• Body Material: Basswood

• Body Shape: Wolfgang®

• Body Finish: Gloss Polyester

• Body Binding: 1-Ply Cream

Neck

• Neck Material: Quartersawn Baked Maple

• Neck Construction: Bolt-On with Graphite Reinforcement

• Neck Shape: Wolfgang® Backshape

• Neck Thickness: .805" at 3rd fret, .890" at 12th fret

• Neck Finish: Hand-Rubbed Satin Urethane

• Scale Length: 25.5" (64.77 cm)

• Fingerboard Material: Baked Maple

• Fingerboard Radius: 12"-16" Compound (304.8 mm to 406.4 mm)

• Number of Frets: 22

• Fret Size: Jumbo

• Nut Material: Floyd Rose® R2 Locking

• Nut Width: 1.625" (41.3 mm)

• Position Inlays: Black Dot

• Side Dots: Black

• Truss Rod Nut: Heel-Mount Adjustment Wheel

• Truss Rod Wrench: 2.5 mm Hex

• String Trees: Floyd Rose® Retainer Bar

• Headstock: EVH® Wolfgang®

Electronics

• Pickup Configuration: HH

• Neck Pickup: Direct Mount EVH® Wolfgang® Humbucking

• Bridge Pickup: Direct Mount EVH® Wolfgang® Humbucking

• Controls:

  • Volume (500K EVH® Bourns® Low Friction Pot) w/ Treble Bleed

  • Tone (250K EVH® Bourns® High Friction Pot)

• Pickup Switching: 3-Position Toggle

  • Position 1: Bridge Pickup

  • Position 2: Bridge + Neck Pickups

  • Position 3: Neck Pickup

Hardware

• Bridge: EVH®-Branded Floyd Rose® Locking Tremolo w/ EVH® D-Tuna®

• Tremolo Arm: Floyd Rose® 1000 Series Locking

• Tremolo Block: Brass

• Tuning Machines: EVH®-Branded Gotoh®

• Hardware Finish: Chrome

• Control Knobs: Black Knurled w/ White Indicator

• Switch Tip: Black

• Strap Buttons: Oversized

Strings

• Factory Strings: EVH® Nickel Plated Steel (.009-.042)

Accessories

• Included: Tremolo Arm, Hex Keys, User Manual

• Optional Case:

  • EVH® Wolfgang® Hardshell Case (p/n 009-0916-000)

  • EVH® Black Gig Bag (p/n 022-1512-006)
