Gibson 1963 Firebird V Murphy Lab with Maestro Vibrola Light Aged, Cardinal Red
Interest FREE financing available at checkoutWhen Gibson hired famed automotive designer Ray Dietrich to create a radical new solid body guitar, rock 'n roll history ensued. With its offset shape, neck-through construction, and scorching mini-humbuckers™, the '63 Firebird™ V became an instant classic. The Gibson Custom Shop is proud to present this exacting replica of a vintage original, which uses authentic contours, dimensions and construction methods for an incredible ownership and playing experience. It features Light Aging by the skilled artisans of the Murphy Lab. The Murphy Lab Light Aged finish treatment, paired with lightly aged hardware, simulates decades of natural play wear, giving it the unique character, vibe, and feel of an original example from the Gibson Golden Era.
Specifications
BODY
- Body Style: Firebird
- Body Shape: Designer
- Body Material: Layered Mahogany
- Body Finish: Murphy Lab Aged Nitrocellulose Lacquer
- Weight Relief: None
NECK
- Profile: Medium C
- Scale Length: 628.65 mm / 24.75 in
- Fingerboard Material: Indian Rosewood
- Fingerboard Radius: 304.8 mm / 12 in
- Neck Material: 9-ply Mahogany/Walnut Neck-Through
- Fret Count: 22
- Frets: Authentic Medium-Jumbo
- Nut Material: Nylon
- Nut Width: 42.85 mm / 1.687 in
- End of Board Width: 56.89 mm / 2.239 in
- Inlays: Aged Cellulose Nitrate Trapezoid
- Joint: Neck-Through Construction
HARDWARE
- Finish: Nickel; Murphy Lab Light Aged
- Bridge: ABR-1
- Saddle Material: Nickel-plated Brass
- Tailpiece: Maestro Vibrola
- Tuning Machines: Deluxe Banjo Tuners
- Pickguard: 3-Ply White/Black/White Firebird Hot-stamped
- Truss Rod: 2-way Adjustable
- Truss Rod Cover: Black 1-Ply Gibson Hot-stamped
- Control Knobs: Black Top Hats with Silver Inserts
- Switch Tip: Cream
- Control Covers: Black
- Strap Buttons: Aluminum
- Pickup Covers: Nickel
ELECTRONICS
- Neck Pickup: Firebird Alnico 5
- Bridge Pickup: Firebird Alnico 5
- Controls: 2 Volume, 2 Tone, 500K CTS Potentiometers, Hand-Wired Harness with Black Beauty Capacitors
- Pickup Selector: 3-Way Switchcraft
- Output Jack: 1/4" Switchcraft
MISCELLANEOUS
- Strings Gauge: .010, .013, .017, .026, .036, .046
- Case: Custom Shop Hardshell
-
Accessories:
- Certificate of Authenticity
