Jackson Pro Series Signature Misha Mansoor Juggernaut HT7, Ebony Fingerboard, Silverburst Sparkle

Djent forefather and speed demon Misha Mansoor has gained widespread acclaim as the mastermind behind the axe-centric progressive metal band Periphery. He's known to impress the most discerning of metal fans with his steadfast, fleet-fingered technique, and his personally designed collection of Jackson signature Juggernaut instruments is sure to set any shredder's tone ablaze.

The Pro Plus Series Signature Misha Mansoor Juggernaut HT7 offers a 26.5"-scale length, poplar body, bolt-on caramelized maple neck with graphite reinforcement for rock-solid stability, wrap-around heel and oiled back finish for greater playing comfort. Enjoy blazing fast leads with a 20" flat radius ebony fingerboard featuring rolled edges, 24 jumbo stainless seteel frets and offset dot inlays. Luminlay® side-dots will guide your way even on the darkest of stages, while the heel-mount truss rod adjustment wheel allows for convenient neck relief tweaks.

Not willing to sacrifice tone, Mansoor spent considerable time working with Jackson to develop killer-sounding Jackson uncovered direct mount MM1 pickups, which can be shaped with a five-way blade switch, single volume control and single tone control with push/pull (activation) feature.

Available in Signal Yellow and Silverburst Sparkle with a matching Jackson 4x3 AT-1 headstock, this sig axe also features a Jackson HT7 string-through-body hardtail bridge, die-cast locking tuners and black hardware.

Features

• 26.5" scale length
• Poplar body
• Bolt-on caramelized maple neck with graphite reinforcement, scarf joint and oiled back finish
• 20" radius ebony fingerboard with rolled edges
• 24 jumbo stainless steel frets
• offset white dot inlays
• Heel-mount truss rod adjustment wheel
• Luminlay® side dots
• Uncovered direct mount Jackson MM1 pickups
• Five-way blade switch, single volume control and single tone control with push/pull select feature
• Jackson HT7 string-through-body hardtail bridge
• Horizon Devices Strings - Progressive Tension Standard 7
• Available in Signal Yellow and Silverburst Sparkle with a matching Jackson 4x3 AT-1 headstock and black hardware
• Gig bag included

Specifications

General

• Series: Artist Signature

• Orientation: Right-Hand

• Color: Silverburst Sparkle

• Country of Origin: Indonesia

Neck

• Headstock: Jackson® AT-1 4x3 (4 Over/3 Under)

• Neck Material: Caramelized Maple

• Neck Finish: Oiled

• Neck Construction: Bolt-On with Graphite Reinforcement and Scarf Joint

• Fingerboard Radius: 20" (508 mm)

• Fingerboard Material: Ebony

• Position Inlays: Offset White Dot

• Number of Frets: 24

• Fret Size: Jumbo Stainless Steel

• Truss Rod: Dual-Action with Wheel

• Truss Rod Nut: Heel-Mount Truss Rod Adjustment Wheel

• String Nut: Black Plastic

• Nut Width: 1.75" (44.45 mm)

• Nut Material: Black Plastic

Body

• Body Shape: Juggernaut

• Body Material: Poplar

• Body Finish: Gloss

Hardware

• Bridge: Jackson® HT7 String-Through-Body Hardtail

• Pickup Covers: Black

• Pickguard: None

• Control Knobs: Dome-Style

• Switch Tip: Black

• Hardware Finish: Black

• Tuning Machines: Jackson® Sealed Die-Cast Locking

• Strap Buttons: Dunlop® Dual-Locking

• Strings: Horizon Devices Strings - Progressive Tension Standard 7

• Neck Plate: 4-Bolt (Recessed Screws)

Electronics

• Pickup Configuration: HH

• Bridge Pickup: Jackson® Uncovered MM1

• Neck Pickup: Jackson® Uncovered MM1

• Controls: Volume, Tone (with Push/Pull Select Feature)

• Switching:

  • Position 1: Full Bridge Pickup

  • Position 2: Two Inside Single Coils

  • Position 3: Both Full Humbucking Pickups

  • Position 4: Outer Neck Single Coil

  • Position 5: Full Neck Pickup
