Charvel Pro-Mod Plus San Dimas Style 1 HH FR E, Ebony Fingerboard, Scorched Earth

Description

Take your shredding to the next level with the all-new Pro-Mod Plus San Dimas from Charvel. This modernized take on the classic San Dimas shred machine packs even more cutting-edge features for lightning-fast playing.

The super-stable caramelized bolt-on maple neck with graphite reinforcement rods offers rock-solid stability regardless of temperature or environment. The 12"-16" compound radius ebony fingerboard has smoothly rolled edges and 4mm pearloid dot inlays for effortless riffing. The thin, fast D-shaped neck profile and 22 jumbo frets also enhance speed and playability. Luminlay® side-dots will light the way even on the darkest of stages.

The powerful Seymour Duncan® JB™ bridge and '59™ neck humbuckers deliver thick, singing tone perfect for everything from crunchy rhythms to blistering leads. Dial in your sound with the 5-way blade switch. Keep your axe in tune through dive bombs and whammy tricks thanks to the Floyd Rose® 1500 double-locking tremolo.

With its sleek matching painted headstock, comfortable new hand-shake heel design, and recessed neck screws, this Pro-Mod Plus San Dimas looks as good as it plays. The alder body resonates with rich, dynamic tone. Stand out from the crowd with your choice of eye-catching finishes.

When your playing demands the ultimate in shred-ready features, Pro-Mod Plus San Dimas is the clear choice. Feel the difference Charvel quality makes.

Features

• 25.5" scale length
• Alder body
• Caramelized bolt-on maple neck
• 12"-16" compound radius ebony fingerboard
• 22 jumbo frets
• Recessed Floyd Rose® 1500 double-locking tremolo
• Seymour Duncan® JB™ TB-4 bridge and Seymour Duncan '59™ SH-1N neck pickups
• 5-way blade switch
• Matching headstock
• Thin D-shape neck profile
• Hand-shake heel design with recessed neck screws
• Luminlay® side-dots
• Gig bag included

Specifications

General

Series: Pro-Mod Plus
Orientation: Right-Hand
Color: Scorched Earth
Country of Origin: MX

Neck

Headstock: Licensed Fender® Stratocaster®
Neck Material: Caramelized Maple
Neck Finish: Hand-Rubbed Urethane
Neck Construction: Bolt-On with Graphite Reinforcement
Fingerboard Radius: 12"-16" Compound Radius (304.8 mm to 406.4 mm)
Fingerboard Material: Ebony
Position Inlays: 4mm Pearloid Dot
Side Dots: Luminlay®
Number of Frets: 22
Truss Rod: Dual-Action with Wheel
String Nut: Floyd Rose® 1500 Series Locking
Nut Width: 1.6875" (42.86 mm)
Nut Material: Floyd Rose® 1500 Series Locking

Body

Body: Alder
Body Finish: Satin
Body Shape: San Dimas®
Body Style: Solid Body
Body Material: Alder

Hardware

Bridge: Floyd Rose® 1500 Series Double-Locking Tremolo
Pickup Covers: Black
Control Knobs: Dome-Style
Hardware Finish: Black
Tuning Machines: Charvel® Branded Gotoh® Die-Cast
Strings: Nickel Plated Steel (.009-.042 Gauges)
Tremolo Arm: Floyd Rose® 1500 Series Locking
Strap Buttons: Standard

Electronics

Bridge Pickup: Seymour Duncan® JB™ TB-4
Neck Pickup: Seymour Duncan® '59™ SH-1N
Pickup Configuration: HH
Controls: Volume (Bourns® Low Friction Pot), No-Load Tone
Switching:

• Position 1: Bridge
• Position 2: Bridge Outer Coil and Neck Inner Coil
• Position 3: Bridge and Neck
• Position 4: Bridge Inner Coil and Neck Outer Coil
• Position 5: Neck

Measurements

Fret Size: Jumbo
Scale Length: 25.5" (64.77 cm)
