Rode RodeCaster Video and Audio Production Console

• Switch between up to six video sources and seven fully customisable scenes at the press of a button
• High-performance octa-core CPU video and audio processor
• Four full HD (1080p) HDMI inputs with auto frame rate conversion and two configurable HDMI outputs for viewing program, preview and multiview
• Two flexible USB-C ports for connecting compatible webcams and RØDE USB audio devices to use as additional video and audio sources
• Two studio-grade Neutrik® combo jacks with ultra-low-noise, high-gain Revolution Preamps™ for capturing pristine audio from XLR microphones, instruments or any other audio source
• Dual internal wireless receivers for connecting RØDE Series IV wireless microphones
• Powerful APHEX® audio processing, including an EQ, compressor, noise gate, high-pass filter, de-esser and the legendary Aural Exciter™, Big Bottom™ and Compellor™ effects
• 2-inch high-resolution touchscreen and versatile rotary encoder for quick configuration and setting adjustment
• Ability to create seven complex scenes with multiple layers of video, media and graphics, which can be saved and triggered at the touch of a button
• Automatic chroma keying for effortlessly replacing backgrounds with media or live video inputs
• Media playback, graphic overlays, keying, transitions and multi-source scene creation all accessible from the front panel
• Innovative "Inspect" feature for quick-and-easy preview and configuration of any input or scene
• Intelligent auto-switching for seamless hands-free switching of video sources and scenes based on audio inputs
• Stream directly to all major platforms via Wi-Fi or Ethernet, or to streaming software via USB
• Record directly to external USB storage device, including isolated (ISO) recording for post-editing flexibility
• Remote control, user-assignable graphics and media, custom scene building, audio mixing and effects, and other advanced configuration options via RØDE Central
• Designed and made in RØDE’s state-of-the-art facilities in Sydney, Australia
• Built-in NDI® support delivers seamless video-over-IP with up to four inputs and one output via Ethernet, plus iPhone integration through the RØDE Capture app.

Specifications

• Analog Audio Inputs:

  • 2 combo jacks (microphone, line, or instrument) with Revolution Preamps™

• Wireless Audio Inputs:

  • 2 Series IV wireless receivers

• Digital Audio Inputs:

  • USB 1: 2-in/2-out or multichannel (20-in) output

  • USB 1 Chat (via USB 1 port): 2-in/2-out with mix-minus

  • USB 2: 2-in/2-out with MFi support

  • USB 4 & 5: Compatible with RØDE USB microphones and RØDECaster Pro II and Duo

• Analog Audio Outputs:

  • 2 headphone outputs (¼-inch)

  • 2 balanced line outputs (¼-inch, L/R)

• Audio Mixer:

  • 20 possible audio sources (9 stereo channels simultaneously):

    • Combo 1 and 2 (can be combined for stereo)

    • Wireless 1 and 2

    • Video clips

    • Sounds

    • HDMI 1, 2, 3, and 4 (each can be split for two mono)

    • Bluetooth

    • 3 USB audio interfaces (computers)

    • 2 hosting USB audio devices (microphones)

  • 12 Outputs with Custom Routing:

    • Live mix, headphone 1, headphone 2, recording, monitors, USB Main, USB Chat, USB 1, 2, 4, and 5, Bluetooth

  • Each output can be independently configured with:

    • Custom level

    • Mute status

    • Level offset settings for each of the 9 inputs

• Audio Processing:

  • APHEX® VoxLab™ Processing: Per channel

  • Advanced APHEX® Granular Processing on Each Channel:

    • Compressor

    • Equaliser (EQ)

    • De-esser

    • Panning

    • Noise Gate

    • High-pass Filter

    • Aural Exciter™

    • Big Bottom™

• Preamps:

  • Frequency Range: 20Hz – 20kHz

  • Input Gain: Up to 76dB

  • Equivalent Input Noise: -131.5dBV (A-weighted)

• Streaming Sample Rate / Bit Depth: 48kHz / 32-bit

• Recording Sample Rate / Bit Depth: 48kHz / 24-bit
