The RØDECaster Video Core is an innovative all-in-one console for video and audio production, providing a complete solution for producing professional content. Designed for software-based control or as part of a modular production setup with RØDECaster Sync, it offers the same advanced production power as the RØDECaster Video in a streamlined form factor, combining powerful video switching, recording and production tools with a fully integrated professional audio mixer. Delivering seamless integration with the RØDECaster Pro II and RØDECaster Duo for maximum flexibility, the RØDECaster Video Core ensures broadcast-quality results for video podcasts, live streams and studio productions.

Features

• Switch between up to four video sources and five fully customisable scenes
• High-performance octa-core CPU video and audio processor
• Three full HD (1080p) HDMI inputs with auto frame rate conversion and one configurable HDMI output for viewing program, preview and multi-view
• Two flexible USB-C ports for connecting select video and audio devices
• Two studio-grade Neutrik® combo jacks with ultra-low noise, high-gain Revolution Preamps™ for capturing pristine audio from XLR microphones, instruments or any other audio source
• Powerful APHEX® audio processing, including an EQ, compressor, noise gate, high-pass filter, de-esser and the legendary Aural Exciter™, Big Bottom™ and Compellor™ effects
• Turn your RØDECaster Pro II or Duo into a modular production hub with RØDECaster Sync, unlocking expanded audio and video inputs/outputs.
• Support for network cameras (including PTZ operation) with up to four NDI inputs® and one output via Ethernet, plus dual-cam streaming with the free RØDE Capture app for iOS devices
• Media playback, keying, transitions, multi-source scenes, graphic overlays, audio mixing and advanced configuration via the RØDECaster App
• Connect an external SSD via USB to record video or output directly to a computer via UVC
• Remote control, user-assignable graphics and media, custom scene building, audio mixing and effects, and other advanced configuration options via RØDECaster App
• Intelligent auto-switching for seamless hands-free switching of video sources and scenes based on audio inputs
• EDL Export for DaVinci Resolve, importing switch, transition, graphic and timeline data for faster editing in post-production
• Dual USB-C audio interfaces for simultaneous connection to two computers and/or mobile devices
• Stream directly to all major platforms via Ethernet and record directly to an external USB storage device, including isolated (ISO) recording for complete post-editing flexibility.
• Designed and made in RØDE’s state-of-the-art facilities in Sydney, Australia

Specifications

General
Video Input Feeds: 4 Simultaneous
HDMI Inputs: 3 × HDMI Type-A (HDMI 1.4b)
USB (UVC) Inputs: 1 × Multi-function USB-C for UVC Video
HDMI Outputs: 1 × Configurable (Preview, Program, Multiview)

Video Input Frame Rates

1920×1080p:
23.98, 24, 25, 29.97, 30, 50, 59.94, 60 (HDMI only)

1920×1080i:
25, 29.97, 30

Video Output Frame Rates

1920×1080p:
24, 25, 30, 50, 60

Video Streaming Standards

1920×1080p:
23.98, 24, 25, 29.97, 30, 50, 59.94, 60

Video Processing
Video Engine Colour Space: 4:4:4 RGB
Bit Depth: 8-bit

HDMI Input Specifications
Colour Space: 4:4:4 RGB, 4:4:4 YUV, 4:2:2 YUV
Bit Depth: 8, 10, 12-bit

USB Input Specifications
Colour Space: 4:2:2 YUV, 4:2:0 YUV (NV12)

HDMI Output Specifications
Colour Space: 4:4:4 RGB, 4:4:4 YUV
Bit Depth: 8-bit

USB Output Specifications
Colour Space: 4:2:2 YUV
Bit Depth: 8-bit

Video Engine Features
Total Number of Layers: 9 simultaneous in Preview and Program
Downstream Keyers: 2 (Overlays and Logo)
Chroma Keyers: 2 (Green, Blue, Luma)
Media Players: 2 simultaneous
Transitions: SMPTE wipes, dip and fade
True Preview: Display complete scenes and overlays simultaneously in preview and program
Generated Borders: All scenes

Multiview

Displays:
• Program and Preview
• Live inputs, scene and media thumbnails
• Audio mixer and channel status
• Recording, network and storage status
• Run time, date and time information

Media Player

Internal Storage: 24GB

Supported Formats:
Video: MP4
Images: PNG, JPG
Audio: WAV

Audio

Analog Audio Inputs
2 × Combo Jacks (Microphone, Line or Instrument) with Revolution Preamps™

Digital Audio Inputs

USB 1: 2-in / 2-out or Multichannel (20-in) output
USB 1 Chat: 2-in / 2-out with mix-minus
USB 2: 2-in / 2-out with MFi support
USB 4: Compatible with RØDE USB microphones and RØDECaster Pro II / Duo

Analog Audio Outputs

2 × Headphone Outputs (1/4")
2 × Balanced Line Outputs (1/4", L/R)

Audio Processing

APHEX® VoxLab™ Processing per channel

Advanced APHEX® Processing:
• Compressor
• Equaliser (EQ)
• De-esser
• Panning
• Noise Gate
• High-Pass Filter
• Aural Exciter™
• Big Bottom™

Preamps

Frequency Range: 20Hz – 20kHz
Input Gain: up to 76 dB
Equivalent Input Noise: −131.5 dBV (A-weighted)

Audio Recording & Streaming

Streaming Sample Rate / Bit Depth: 48kHz / 32-bit
Recording Sample Rate / Bit Depth: 48kHz / 24-bit

Audio Mixer

16 possible audio sources (9 stereo channels simultaneously):

Sources include:
• Combo Inputs 1 & 2
• Video Clips
• Sound Pads
• HDMI 1 / 2 / 3
• USB Audio Interfaces
• USB Microphones
• Network Sources

Outputs (11 total with custom routing):

• Live Mix
• Headphone 1
• Headphone 2
• Recording
• USB 1 Chat
• USB 1
• USB 2
• USB 4
• Bluetooth
• HDMI A
• Network

Each output can be configured independently with level, mute and offset controls.

Streaming & Networking

Direct Streaming
RTMP / RTMPS over Ethernet

Supported Platforms:
• YouTube Live
• Twitch
• Facebook Live
• Twitter / X Live
• Custom RTMP Server

Network

Ethernet: 10/100/1000 Base-T
Functions:
• Streaming
• Configuration
• Remote Control
• Firmware Updates

Software

RØDE Central Companion Software

Features:
• Scene Builder
• Auto-Switching based on audio input
• Advanced Audio Mixer
• Streaming Profile Management
• Device Configuration

Recording

Storage Media
External USB mass storage (exFAT)

Video Recording
Program Feed: H.264 / AVC MP4 with embedded AAC stereo mix

ISO Video Recording
4 Video Inputs + Program Feed as independent H.264 files (up to 1080p30)

Audio Recording
Stereo Mix WAV file

Multitrack Audio Recording
9 independent stereo WAV files

NDI Support

Protocols: Single TCP, Multicast

Formats: Hx2, Hx3

Video Codecs:
H.264
HEVC / H.265
4:2:0, 8-bit

Audio Codecs:
AAC-LC
L-PCM Stereo 48kHz

Interface: Wired Ethernet

System Compatibility

MacOS: 11 or later
Windows: Windows 10 (1803+) or Windows 11

Power

Power Supply: USB-C PD 45W
Voltage: 20V / 2.25A

Dimensions & Weight

Weight: 705 g

Dimensions:
Length: 239 mm
Width: 125 mm
Height: 45.5 mm
