Yamaha DXR12MKII 12-Inch Two-Way Powered Speaker - 1100W
SKU DXR12MKII
by Yamaha
Original price
$1,099.99
-
Original price
$1,099.99
Original price
$1,099.99
$1,099.99
$1,099.99
-
$1,099.99
Current price
$1,099.99
Estimated time before shipping to be confirmed after you place your order.
×
Know the delivery date before ordering
Interest FREE financing available at checkoutThe DXR12mkII is an extremely high-power loudspeaker that is capable of producing a maximum SPL of 134dB with its impressive 1100W of power. It is the perfect solution for live sound applications that demand wide bandwidth and extremely high-resolution sound.
General specifications
| Speaker type | - | 12" 2-way, Bi-amp powered speaker, Bass-reflex type |
|---|---|---|
| Frequency range (-10dB) | - | 52Hz - 20kHz |
| Nominal coverage | H | 90° |
| V | 60° | |
| Components | LF | Diameter:12" cone, Voice Coil:2.5", Magnet:Ferrite |
| HF | Diaphragm:1.75", Type: 1" throat compression driver, Magnet:Neodymium | |
| Crossover | - | FIR-X tuningâ„¢ (linear phase FIR filter) |
| Output power | - | Dynamic:1100W (LF: 950W HF: 150W) / Continuous: 700W (LF: 600W HF: 100W) |
| Number of fans | - | 134dB SPL |
| I/O connectors | - | INPUT: XLR-3-31 x1 , INPUT2: Phone x2, INPUT3: RCA PIN x 2, THRU: XLR3-32 x 1 (Parallel with INPUT 1 ), LINK OUT: XLR x 1 |
| Processors | - | D-CONTOUR: FOH/MAIN, MONITOR, OFF |
| Power requirements | - | 100V - 240V, 50Hz/60 Hz |
| Power consumption | - | 110W |
| Flying and mounting hardware | - | Top x2, Rear x1 (Fits for M10 x 18mm eyebolts) |
| Pole socket | - | 35mm with 2-way features (0 or 7 degrees) |
| Dimensions | W | 362mm (14 2/8") |
| H | 601mm (23 5/8") | |
| D | 350mm (13 6/8") | |
| Net weight | - | 18.6kg (41.0lbs) |
| Accessories | - | UB-DXR12 (U-bracket) |
| Others | - | Material: ABS (Matte Finish, Black |
